MS-210SP



HDBaseT Extender Set – 4K to 40m (10G), 70m @ 1080p. PoE / PoH, S/PDIF, one-way analogue audio pass-through, RS-232 pass through, with single channel bi-directional IR. HDCP2.2 compliant

The MSolutions MS-210SP is a 4K HDMI HDBaseT extender set allowing for uncompressed video and audio to be extended up to 40m at 4K UHD & HDR (10.2Gbps), and 70m at 1080p or lower resolutions. S/PDIF audio return enables the sink to return audio to an audio amplification or distribution device located remotely to the display. An additional one way analogue audio pass-through allows for a separate audio signal to be returned from the receiver to the transmitter. The unit also features RS-232 serial pass-through and single channel IR pass through from TX to RX, or RX to TX. HDBaseT compliant PoE allows for the RX unit to be powered remotely from the TX.



  • Uncompressed extension of HDMI at resolutions up to 4K 60Hz 4:2:0 / 4K 30Hz 4:4:4 using HDBaseT technology

  • 4K signal extension to 40m over single CAT including HDR formats suppported under 10.2Gbps

  • 1080p or lower video resolutions up to 70m over single CAT

  • Supports HDMI pass-through all known HDMI audio formats including Dolby Atmos / DTS:X

  • HDBaseT 48V standard PoE support to power RX from the TX

  • Bi-directional S/PDIF (Digital Optical Toslink) connectivity (TX to RX, RX to TX)

  • Independent 1-way analogue audio pass-through (RX to TX)

  • Bi-directional RS-232 serial pass through

  • Single channel 5V IR pass-through (TX to RX, or, RX to TX)

  • CEC (Consumer Electronics Control) pass through

  • HDCP2.2 compliant



Technical Specifications:

  • Video connectivity TX: 1x HDMI input (female), 1x HDBaseT output (RJ45 keystone)

  • Video connectivity RX: 1x HDBaseT input (RJ45 keystone), 1x HDMI output (female)

  • IR connectivity (TX & RX): 1x 3.5mm stereo jack (female) – IR TX or IR RX

  • RS-232 connectivity (TX & RX): 1x 3-pin phoenic connector, block included

  • Power supply (TX): 1x 48V 0.5A DC

  • Power consumption: 15W

  • Individual unit dimensions (W x D x H): 60 x 84 x 25mm

  • Individual unit weight: 0.1kg

  • Package dimensions (W x D x H): 160mm x 130mm x 75mm

  • Package weight: 0.5kg

  • Operating temperature: 32°F to 104°F (0°C to 40°C)

  • Storage temperature: -4°F to 140°F (-20°C to 60°C)

  • Operating humidity: 0-80% non condensing
